Mutant Metals Ultimate Dip Attachment (UDA)
Mutant Metals Ultimate Dip Attachment (UDA)
5/8” Pin is Compatible with Rogue Monster Lite Uprights
Choose Color (5)*Textured Black
3 Ships Free Item
Product Description
The Ultimate Dip Attachment (UDA) from Mutant Metals is now available in several exclusive Rogue-built variations. This modular rack attachment is compatible with both Monster and Monster Lite units, and features removable, knurled handles, enabling athletes to adjust the handle spacing to best suit their size and training goals.
Read More
Mutant Metals Ultimate Dip Attachment (UDA)
The Ultimate Dip Attachment (UDA) from Mutant Metals is now available in several exclusive Rogue-built variations. This modular rack attachment is compatible with both Monster and Monster Lite units, and features removable, knurled handles, enabling athletes to adjust the handle spacing to best suit their size and training goals.
2 Different Rack Mount Options
- 5/8" Pin: Compatible with Rogue Monster Lite Uprights
- 1" Pin: Compatible with Rogue Monster Uprights
Multiple Colors & Finishes
- Textured Black, Textured Red, Textured Charcoal Gray, Textured Dark Blue or Gun Metal
- Proprietary Matte Black or Stainless Steel Handles
3 Handle Ranges
- Position 1: 11.5 - 20”
- Position 2: 15 - 24”
- Position 3: 19 - 27.5”
The attachment mounts easily to an upright using either an integrated 1” stainless pin (for Rogue Monster) or removable ⅝” detent pin (for Rogue Monster Lite). Handle adjustments can be made quickly from one athlete to the next using the Rogue patented knurled knob. The 1-3/8” diameter handles provide 18” of usable length, and they’re available in two finish options: stainless steel or our proprietary matte black. Convenient knurl marks appear every 6” along each handle to help the user find and repeat a comfortable starting position from workout to workout. We have also included protective UHMW on all contacting surfaces to help protect both the attachment and the rack upright (this protection still applies when the UDA is in “storage mode”).
*The Textured Black / Proprietary Matte Black Handle UDA includes a non-stainless, powder coated pin.
Gear Specs
Specifications:
- Made in the USA
- Available as a 1” welded stainless pin or 5/8” hole and detent pin
- 2x2” 11-gauge and 3/8” thick welded steel frame
- 12.6 LB Frame, ~8.6 LB per handle
- 3 Handle Width Options
- Handle Diameter of 1 3/8”
- Handle Finish Options: Proprietary Matte Black Knurled or Stainless Steel Knurled (with knurl marks every 6”)
- Usable Handle Length: 18”
- Built in storage (with plastic protection)
- Textured Black, Textured Red, Textured Charcoal Gray, Textured Dark Blue or Gun Metal frame finish
- Max Handle Width: approx 27.5”
- Min Handle Width: approx 11.5”
- Dims: 21.25 W x 6.75 H x 24.5 D (from mounting upright)
- Weight limit: 550LB
Shipping
Rogue Fast Shipping
The Rogue Shipping System allows you to track your order from the time you place it to the time it hits your door. Order today, track today.
Gear Specs | |
Brand | Mutant Metals |
Made In USA | Yes |
Product Weight | 31LB |
Length | Approximately 24.5" (depth from mounting upright - varies based on handle position) |
Width | 21.25" (Frame) |
Height | 6.75" |
Diameter | 1-3/8" / 35mm (Handle) |
Steel Notes | 2 x 2" 11-Gauge Steel / ⅜” Steel Plates |
Other Product Specs | 18" Usable Handle Length |
Key Features of the UDA
Designed in Partnership with Mutant Metals
The Ultimate Dip Attachment was first developed by Mutant Metals, a family owned and operated manufacturer of quality strength training equipment, based in western Pennsylvania. Rogue is pleased to work with Mutant Metals on adapting our own versions of this accessory which are manufactured here in Columbus, Ohio.
Removable Handles - 3 Width Options
The UDA creates an instant dip station on an existing 3x3” Monster or Monster Lite rack/rig, attaching securely via an included pin (1” for the Monster version, 5/8” for the Monster Lite). The attachment’s 1-3/8” diameter handles can also be removed and placed in one of three holes, then secured quickly using the Rogue patented knurled knob . This creates three handle width options with their own grip spacing ranges: Narrow (11.5” - 20”), Mid (15” - 24”), and Wide (19” - 27.5”). The handles will remain at the same 30-degree angle in relation to one another no matter where they are positioned.
Handle Knurling + 2 Finish Options
All UDA handles have 18” of usable length and are knurled for a superior grip, with convenient knurl marks provided every 6” to help athletes repeat comfortable starting grip positions. Customers can select between a stainless steel handle finish or our proprietary matte black finish, which utilizes a process that effectively transforms the surface of the steel rather than coating it, greatly increasing the handles’ long-term corrosion resistance and color endurance.
Quality Rogue Construction
Rogue has made some notable adaptations to the original Mutant Metals UDA design, including the use of a single-piece formed and welded tube; reinforcement of the frame with a tubular triangle gusset; and the introduction of a Rogue patented knurled knob for set-up with an integrated protective plastic washer. All welded joints are also slotted/tabbed prior to welding for additional structural strength. Tight tolerances are enforced to ensure a more snug fit on the upright. Every Ultimate Dip Attachment we manufacture is fully built out and tested, with modifications made to any that don’t meet the tightness requirements.
